New signal converter launched

LinkedIn +

VSE Flow has released the FU210-28 converter for processing speed information from output signals of its VSE flow meters.

The device can convert the frequency of HTL (high-threshold-logic) signals into a freely scalable analogue measurement variable (current/voltage. With an analogue 16bit resolution, or as a digital measured value via Modbus RTU or RS232, the converted signals can be analyzed further. To increase accuracy a linearization of up to 24 control points can be programmed.

In addition to quadrature signals with HTL signals, the converter can process the formats RS422, TTL and HTL differential formats, as well as single-channel signals from other measuring systems such as incremental encoders.

The FU210-28 also has pulse counting mode, which enables conversion of the total flow rate (volume). Linearization can also be programmed in this operating mode.

The unit has six inputs and outputs.
