Long-time exhibitor National Instruments will be showcasing its InstrumentStudio software for NI PXI modular instruments at this year’s Automotive Testing Expo Europe 2018.
InstrumentStudio improves the live, interactive use model for modular instruments and makes debugging while running tests more intuitive. As a result, engineers benefit from a more effective workflow for test system development.
InstrumentStudio evolves the concept of single-instrument soft front panels into a unified, multi-instrument environment, so engineers can capture screenshots and measurement results in one view from their suite of instruments.
InstrumentStudio can also save project-level configurations for specific devices under test that can be repurposed later or shared with colleagues. This efficiency is key for testing high-mix devices and provides test repeatability at a convenience to the engineer or technician.
At different stages in the product design cycle, test engineers often waste valuable time correlating measurements between similar tests that ultimately use different hardware. And in production tests, engineers who need to debug on the manufacturing floor may invest in separate hardware either for monitoring their tests or debugging their automated test equipment.
InstrumentStudio addresses these challenges by exporting configuration files to programming environments that reproduce settings, thereby simplifying measurement correlation.
Additionally, test engineers can monitor PXI instrument behavior by running InstrumentStudio while test sequences execute in parallel, streamlining the debug process. Through these seamless interactions with programming environments and test sequences, InstrumentStudio becomes an important part of a comprehensive software workflow and helps engineers maximize their investment in PXI instrumentation.
“For two decades, test and validation engineers have reduced their total cost of test and brought products to market faster using modular instruments on the PXI platform,” said Luke Schreier, vice president of product marketing at NI.
“InstrumentStudio makes using NI PXI instruments even easier – from initial product discovery to system debugging – all with intuitive connections to programming environments and test sequencers. It’s a valuable tool in unlocking the full potential and usability of your bench or automated test rack.”
Visit National Instruments at booth 1324 at Messe Stuttgart, Germany, on June 5-7.
